Description
| Frame |
Aluminum, 9x135mm QR, 24″ |
| Fork |
SR Suntour XCT Coil w/Soft Spring and Preload, 80mm, 9X100 QR |
| Rear Shifter |
Shimano SL-RV200-6R, 6sp, gripshift |
| Rear Derailleur |
Shimano TZ-500, 6sp, Direct mount |
| Crankset |
Alloy 3pc, 140mm, 28T Narrow Wide |
| Bottom Bracket |
Sealed bearing, ST 68mm |
| Cassette |
Shimano MF-TZ500-6, 14-28T, 6sp, Freewheel |
| Chain |
KMC Z6 |
| Front Brake |
Tektro Aries, Resin pads, Mechanical Disc |
| Front Brake Rotor |
160mm, 6-Bolt |
| Rear Brake |
Tektro Aries, Resin pads, Mechanical Disc |
| Rear Brake Rotor |
160mm, 6-Bolt |
| Brake Levers |
Tektro Aries alloy Jr. Levers w/reach adjust |
| Handlebar |
Alloy Jr. Riser, 600mm, 30mm Rise |
| Stem |
Alloy 40mm Length, 31.8mm Clamp |
| Seatpost |
Norco Alloy 27.2mm, 250mm length |
| Headset |
External Cup Ball Bearing, 1-1/8″ EC 34 |
| Headset Spacer |
1x10mm , 2x5mm |
| Saddle |
Norco Jr XC, Steel Rail |
| Grips |
Norco Youth, 115mm Length |
| Pedals |
Jr. MTB Flat, 9/16″ |
| Seatpost Clamp |
Norco Alloy Bolted, 31.8mm ID |
| Front Hub |
Formula DC-1420 , 9x100mm QR, 28h, 6-bolt |
| Rear Hub |
Formula DC-31R-7S, 9x100mm QR, Freewheel, 28h, 6-bolt |
| Rims |
Aluminum DW, 28h, 24″ MTB |
| Front Tire |
CY Trail, 24×2.25″, Wire |
| Rear Tire |
CY Trail, 24×2.25″, Wire |
| Spokes/Nipples |
Stainless Steel w/Brass Nipples – Black |
| Weight |
12.04 kg (26.5 lbs) |
