Adventure Neo Bike Spare Components (2019–2022)

Description

Adventure Neo 2019 – 2022 Spares

• Head Tube – Upper 1-1/8 in, LWR 1-1/2 in
• Headset – Integrated 1-1/8 in – 1-1/2 in
• Bottom Bracket: Type / Width – Bosch Drive Unit
• Front Derailleur – N/A
• Seat Post: Dia./Binder – 31.6mm/36.4mm
• Min. Seat Post Insert – 75 mm
• Max. Frame Seat post Insert Depth – S-215mm, M-240 mm, L & XL – 323 mm
• Tire Size x Max. Width – Big Ben Plus ETRTO 55-622 (28 X 2.15 Zoll)
• Max. Fork Length – 510mm
• Max. Water Bottle Mounting Bolt Length – 12mm
• Max. Rear Rack Weight Limit – 20kg
• Brakes: Mount Type/Min/Max Rotor Diameter – Post Mount / 180 mm/203 mm
• Axles: Type/Length – RR: Maxle TA/148×12 mm, 188 mm Overall Length
• Max. Weight Limit: Total – 138kg
• External Battery Compatible – No
